ML Requirements

IoT Platform Modules

Local Inference

AI workloads are compute-intensive due to their reliance on matrix operations and convolutional layers, especially in vision and audio. The required hardware depends on the model’s size and complexity:

  • CPUs (general-purpose): Sufficient for tiny models like keyword spotting
  • Accelerators (GPU/TPU/NPU): Required for more demanding tasks like object detection or full image classification
  • Examples:
    • ESP32, STM32: Suitable for 8-bit classifiers or tinyML workloads
    • Raspberry Pi: Can handle quantized CNNs with TFLite
    • Coral Edge TPU, Nvidia Jetson: Best for real-time video or multi-class object detection

💡 A MobileNet model (~4MB quantized) may run at ~20 FPS on a Jetson Nano or Coral, but would be infeasible on most MCUs.

Software and Frameworks

Here’s the typical workflow for deploying a model to the edge:

  1. Train your model in TensorFlow, PyTorch, or Keras
  2. Convert to a lightweight format (e.g., TFLite, ONNX, Edge Impulse)
  3. Optimize using quantization (INT8), pruning, or knowledge distillation
  4. Deploy the model via an OTA mechanism or build pipeline

Recommended tools:

  • Frameworks: TensorFlow Lite, ONNX Runtime, PyTorch Mobile, Edge Impulse, TinyML
  • Optimization: TFLite Converter, Post-training quantization, TVM
  • Deployment: Ioto OTA, PlatformIO, MCUboot

Challenges and Considerations

Memory & Compute Limits

  • Most MCUs offer 128KB–2MB RAM
  • Even mid-size models (1–5MB) require at least 256MB RAM and a fast CPU
    Power Constraints
  • Always-on inference drains battery; models must balance speed and efficiency
  • Use hardware sleep modes and edge-optimized runtimes
    Security & Privacy
  • Models and firmware should be encrypted and verified with secure boot / update
  • Keep inference on-device to limit data exposure
    Model Tradeoffs
  • Quantization and compression reduce size but may cost accuracy
  • Quantization-aware training helps maintain fidelity
    Data Labeling
  • Quality labeled data is still the biggest challenge
  • Synthetic datasets, semi-supervised learning, and transfer learning can help

Invocation of Cloud Models

Some AI tasks are simply too big or complex for the edge. Invoking cloud-hosted models enables edge devices to offload processing to powerful infrastructure. Cloud models are evolving extremely rapidly, and are now capable of handling new and surprising tasks each day.

When to Use Cloud Inference

  • Large models: GPT, BERT, ResNet, YOLOv7
  • High-res input: 4K video frames, long audio segments, multimodal data
  • Non-real-time decisions: Environmental analysis, compliance audits
  • Low-frequency analytics: Monthly usage reporting, exception detection
  • Cloud workflows: Triggering business logic or third-party integrations

Invoking Cloud Models

Edge devices can invoke cloud AI in multiple ways:

  • Direct Call: Use REST API or WebSocket to call the cloud model and get a response
  • Local Agent: The device agent functions as an agent workflow conductor calling cloud models and implementing local tools/functions to implement an agentic workflow
  • Automated Trigger: Device sensor data posted to the cloud triggers IoT platform automations that then invoke the cloud model with the device data and return the result to the device

Hardware Required for Cloud Invocation

  • Edge device: Only needs enough compute to pre-process and transmit data to the cloud and issue REST API or WebSocket calls.
  • Connectivity: Wi-Fi, LTE, Ethernet
  • Examples:
    • ESP32: Sends metrics via HTTPS or WebSockets
    • STM32 + LTE: Triggers remote workflows
    • Raspberry Pi: Supports TLS, JSON formatting, and HTTPS clients

Hybrid Edge AI

Hybrid AI combines fast local inference with cloud-powered intelligence, giving devices both autonomy and access to advanced processing when needed.

When to Use Hybrid AI

  • Local inference is sufficient most of the time, but the cloud is needed when:
    • Results are uncertain
    • Confidence scores fall below a threshold
    • Historical or comparative analytics are needed
    • A workflow needs to be triggered

Benefits of Hybrid AI

  • Latency: Local responsiveness
  • Intelligence: Cloud-based fallback or secondary analysis
  • Efficiency: Cloud invoked only when needed
  • Workflow integration: Automatically route to appropriate services
  • Resilience: Continue functioning when offline, sync when online

Use Cases

  • Cameras: Local motion detection, cloud facial recognition
  • Wearables: Local vitals monitoring, cloud escalation for irregularities
  • Industrial sensors: Local threshold alerts, cloud trend evaluation

Hardware Requirements

  • Modest on-device compute for initial filtering or classification
  • Reliable network for cloud escalation
  • OTA support for updating hybrid logic and model parameters

AI at the Edge with Ioto

Ioto streamlines the entire process of deploying and managing AI at the edge. Whether you need local, cloud, or hybrid AI, Ioto supports it out of the box.

Ioto Capabilities

  • Local inference: Run TFLite models directly on edge devices like the ESP32
  • Cloud invocation: Use REST, WebSockets, or SSE to call cloud services like OpenAI
  • Hybrid logic: Define confidence thresholds or escalation rules
  • OTA updates: Push models, firmware, and config remotely

Ioto Features

  • Fiber coroutine core: Efficient concurrent task handling
  • Built-in protocols: WebSockets, SSE, HTTP REST
  • OpenAI support: Chat, completions, embeddings, streaming APIs
  • Embedded JSON engine: For fast and flexible data handling

Getting Started: AI with Ioto Sample Project

Let’s walk through a hybrid AI example with Ioto:

Goal: Detect people with an ESP32-CAM, and invoke a cloud model if detection confidence is low.

You’ll Need:

  • ESP32-CAM with Ioto
  • A TFLite object detection model
  • Ioto dashboard for OTA and monitoring

Steps:

  1. Train and optimize a model (e.g., Edge Impulse or TensorFlow)
  2. Quantize and export to TFLite
  3. Deploy via Ioto’s OTA system
  4. Build an alert dashboard with Ioto’s low-code builder
  5. Define hybrid logic: if local confidence < 0.7, invoke OpenAI API for a second opinion

This combines fast local inference with the intelligence of cloud-based AI.

Conclusion

AI at the edge doesn’t have to be all or nothing. You can run models locally, invoke them in the cloud, or combine both in a hybrid system. The right approach depends on your latency, power, privacy, and scalability requirements.

With platforms like Ioto, you can deploy, manage, and scale edge AI easily—whether you’re building a prototype or launching a product line.

Call to Action

Ready to bring intelligence to the edge of your devices?
👉 Explore Embedthis Ioto
👉 Try a sample project or follow our tutorials
👉 Show us what you’re building—we’d love to see your edge AI in action!
